| Style: | Palm Portable | Sampling Rate: | 2times/second |
|---|---|---|---|
| Low Battery Indication: | YES | PRODUCT MODEL: | LX-1336B Vici |
| Resolution: | 0.01 Cd | Sensor Type: | Photo Diode And Filter |
| High Light: | Palm Portable Lux Meter,Portable Lux Meter For LED,TV Lux Test Meter |
||
For LED And TV Lux Test Meter LX-1336B Lux Meter Lux Testing Instrument
Use silicon photocell detector with good stability, strong light resistance and shock resistance, accurate photometric measurement
with strict visual correction; wide measuring range,0.1-2000000cd/m2 without dim mer; Data hold,measurements can be locked Automatic shutdown,power consumption is very low, 9V battery case continuously use for up to 200 hours.
Features of LX-1336B Lux Meter:
1. Display: 3 ½ digits, big LCD, max display 1999.
2. Wide range: from 0.01cd to 20,000cd (total four ranges).
3. Data hold; auto power off.
4. Removable holster
Specifications of LX-1336B Lux Meter:
| Specifications | LX 1336B |
| Repeatability | ±2% |
| Temperature characteristic | ± 0.1%/℃ |
| Auto zero-adjustment | √ |
| Data Hold | √ |
| Low battery indication | √ |
| Auto power off | √ |
| Sensor | Photo diode and filter |
| Sampling rate | 2 times/second |
| Resolution | 0.01 cd |
| Operation way | Manual range |
| Max. Display | 1999 |
| LCD size | 67×40mm |
| Battery | 9V (6F22) |
Technical parament of LX-1336B Lux Meter:
| Range | Accuracy | Result |
| 20 cd | ±5% rdg ± 10. | Reading |
| 200 cd | Reading | |
| 2,000 cd | reading | |
| 20,000 cd | 10×reading |
